Kingtech 12.1 inch 1280*800 IPS LCD display supply is very stable. This 12.1inch supports the LVDS interface. In addition, the 12.1 inch TFT module lifetime is 50000h, the brightness is 400nits sunlight-readable, and this 12.1-inch screen is All/Free/Full/Wide viewing angle/IPS type. For the touch part, Kingtech can custom the touch according to the customer's requirements.
IPS/Free/Full/All/Wide viewing angle
280x800/WXGA
Stable supply
Wide temperature/-20℃~+70℃
Can custom capacitive touch screen
| Item | 12.1inch 1280x800 LCD display |
| Model No | PV012103YH30D |
| Resolution | 1280x800 / WXGA |
| Outline Dimension | 278 (W)×184(H)× 10(T) |
| Active Area(mm) | 261.12 (W)× 163.2(H) |
| Interface | LVDS |
| Brightness | 400nits |
| Viewing Angle | All |
| LED life | 50000h |
| Display Mode | TN / Transmissive / Normally Black |
| PIN | 30 |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -20℃~70℃ |
| Touchscreen | Can custom capacitive touchscreen |
The 12.1inch 1280*800 IPS TFT LCD display can be used for industrial control, agricultural equipment, medical device, game console, and smart home, etc.
