SPI+RGB Interface 5.0 Inch 480x854 Wide View Angle LCD Display

Name: SPI+RGB Interface 5.0 Inch 480x854 Wide View Angle LCD Display
Brand: Kingtech Group Co., Ltd.
Price: 100 USD

Get a Quote Documentation

Kingtech 5inch 480x854 IPS/ free/all/wide/full viewing angle TFT LCD display is mainly used for black-box, smart home device.

This 5inch 24bit RGB interface IPS LCD display has existing capacitive touch, we can also custom LCD module according to the customer's requirements. The life-time can reach 30000 hours.

Features of SPI+RGB Interface 5.0 Inch 480x854 Wide View Angle LCD Display

All/Free/Wide viewing angle
480x854 resolution
IPS LCD touchscreen
3 wire SPI +RGB 24bit interface
Support TFT capacitive touchscreen

Specification of SPI+RGB Interface 5.0 Inch 480x854 Wide View Angle LCD Display

Item	5inch 480x854 vertical display
Model No	PV05002TD40C
Resolution	480x854
Outline Dimension	66.40(W)x120.05(H)x2.06(T)
Active Area(mm)	61.56(W)x109.53(H)
Interface	3 wire SPI +RGB 24bit
Brightness	430nits
Viewing Angle	All
Driver IC	ST7701S
LED life	30000h
Display Mode	TN / Transmissive / Normally Black
PIN	40
Operating Temperature	-20℃~70℃
Storage Temperature	-30℃~80℃
Touchscreen	Can custom capacitive touchscreen

Application of SPI+RGB Interface 5.0 Inch 480x854 Wide View Angle LCD Display

The 5inch IPS LCD display can be used for 3D printers, medical devices, handheld equipment, industrial control, smart Home, POS machine, and a black box.
