Kingtech 7inch 800x480 40pin 18bit RGB interface LCD display supply very stable. It is an alternative solution for Empire. The 7inch TFT module driver IC is HX8262+HX8678. The 7inch WVGA lifetime is 50000h. For the touch part, Kingtech can custom the 7inch touch panel according to the customer's requirements.
Classic 40 pin FPC
800X480 /WVGA resolution
Stable supply
18bit RGB
The alternative solution of Empire
Can custom capacitive touch screen
| Item | 7inch 800x480 40pin 18bit RGB display |
| Model No | PV07005YP40F |
| Resolution | 800x480 |
| Outline Dimension | 165.00*104.54*5.20 |
| Active Area(mm) | 152.40*91.44 |
| Interface | 18bit RGB |
| Driver IC | HX8262+HX8678 |
| Brightness | 430nits |
| Viewing Angle | 12 o'clock |
| LED life | 50000h |
| Display Mode | TN / Transmissive / Normally white |
| PIN | 40 |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touchscreen | Can custom resistive and capacitive touchscreen |
The 7inch 800x480 LCD display can be used for agricultural equipment, medical device, game console, and smart home, etc.
