Overview:
The PV043027D0140X is a high-reliability 4.3 inch TFT LCD display module designed specifically for embedded applications that require cost-efficiency without compromising performance. Featuring a 480×272 resolution, TN panel, and a brightness of 480 nits, this display is suitable for both indoor and semi-outdoor environments. The wide active area and 24-bit RGB interface enable sharp, colorful image reproduction, making it ideal for UI-rich applications.
This model integrates the HX8257A driver IC, ensuring stable performance in industrial environments. It supports optional resistive or capacitive touch screens, making it a flexible solution for a wide range of professional devices.
Application Fields:
-
E-Bike Display Systems – Performance, battery, and speed information displays
-
Medical Monitoring Equipment – Vitals display, portable ultrasound, diagnostic interfaces
-
Hand-held Terminals – Industrial scanners, maintenance tools, control instruments
-
Smart Home Devices – Thermostats, intercom systems, appliance displays
-
Industrial HMI Panels – Automation interfaces, PLC monitors, machinery UI
Customization Services Available:
-
Optical bonding & touch lamination
-
Anti-glare/anti-reflective surface treatment
-
Interface, FPC, connector adjustment
-
Cover glass printing/logo
-
Wide temperature enhancement solutions
-
Touch controller tuning support
