2.4inch 450*600 AMOLED display

2.4inch 450*600 AMOLED display

2.4inch 450*600 AMOLED display

2.4inch 450*600 AMOLED display

2.4inch 450*600 AMOLED display

2.4inch 450*600 AMOLED display

Technical Specifications:

Display Size: 2.4 inch (Diagonal)
Display Type: AMOLED
Resolution: 450 (RGB) × 600 pixels
Brightness: Typically ≥300 nits (Customizable)
Viewing Angle: Full viewing angle, no color shift
Interface: SPI / MIPI (Customizable)
Contrast Ratio: ≥100,000:1
Power Consumption: Ultra-low (depends on content and interface)
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
Touch Options: Supports capacitive/in-cell touch (optional)
Module Thickness: Ultra-thin, suitable for compact systems

Key Features:

High Resolution (450×600): Fine pixel pitch for sharp text and detailed UI/UX
AMOLED Technology: True black, high contrast, and no backlight required
Ultra-Thin Profile: Ideal for space-constrained or wearable applications
Wide Viewing Angle: Excellent visibility from all directions
Fast Response Time: Suitable for real-time visual data or video playback
Power Efficient: Perfect for battery-driven devices
Touch Optional: Support for in-cell or external capacitive touch options
Customization Support: FPC layout, interface, cover lens, bonding, and more

For product pricing,customization,or other inquiries:

Share to:

Description

Overview:
The 2.4 inch AMOLED display module combines high resolution, brilliant contrast, and superior color saturation within an ultra-thin and energy-efficient form factor. With a crisp 450×600 resolution, deep black levels, and excellent viewing performance, this module is ideal for applications that demand visual clarity, compact integration, and low power consumption.

Built using AMOLED (Active Matrix Organic Light-Emitting Diode) technology, the display eliminates the need for a backlight, making it thinner, lighter, and more power-efficient than traditional LCDs. Its ability to deliver real black, wide color gamut, and fast response times makes it perfect for wearable devices, medical instruments, and industrial handheld terminals.

The display supports optional touch integration (capacitive or in-cell) and can be customized to meet unique mechanical and electrical requirements.

✅ Applications:

Wearable Devices: Smartwatches, fitness bands, AR/VR components
Medical Equipment: Portable diagnostics, fingertip monitors, test modules
Industrial Handhelds: Barcode scanners, data collectors, portable terminals
Consumer Electronics: Compact control panels, remote controllers, small UI modules
Smart Home Devices: Thermostats, intercoms, remote input panels
Automotive Components: Dashboard add-ons, secondary infotainment elements

Optional Custom Services:

Custom interface type (SPI, MIPI, etc.)
In-cell or external capacitive touch screen integration
Optical bonding with anti-glare or anti-fingerprint coating
Cover lens with logo printing and silk screen design
Driver board and system integration support
Extended temperature/brightness support for outdoor or harsh environments
Low power mode optimization for wearable products

Why Choose AMOLED from Us?

Mature supply chain and stable long-term availability
Strict quality control and engineering support (ISO9001, ISO13485 certified)
Strong support for prototyping and quick customization
Used by top brands in medical, industrial, and consumer sectors
Dedicated team for project integration, from prototype to mass production
