Kingtech 0.96 inch 80×160 resolution LCD display

Item0.96 inch 80×160 resolution IPS LCD display
Model No.PV096003D0113C
Resolution80*160
Outline Dimension (mm)13.5*27.95*1.6
Active Area (mm)10.8* 21.7
Viewing AngleIPS
Brightness300nits
Interface4 line SPI
Backlight/
Driving ICNV3022B
PIN No.13
Operating Temperature-20℃~70℃
Storage Temperature-30℃~80℃
Touch screenCan custom resistive and capacitive touch screen
ApplicationMedical, hand-held device, industrial, smart watch

For product pricing,customization,or other inquiries:

Share to:

  1. TFT LCD
  2. 80X160
  3. Stable supply
  4. IPS
  5. SPI interface
  6. 300nits brightness
  7. Can custom resistive touch and capacitive touch
  8. Medical, hand-held device, industrial, smart watch

0.96 inch 80x160 TFT LCD0.96 inch 80x160 TFT LCD

0.96 inch 80x160 TFT LCD
