Item | 3.97”IPS 1280*720 TFT display |
Model No. | PV04018H0530S |
Resolution | 1280*720 |
Outline Dimension (mm) | 93.08*58.76*2.71 |
Active Area (mm) | 87*94*49.46 |
Viewing Angle | All |
Brightness | 1000nits |
Interface | LVDS |
Backlight | 7*2LEDs |
Driving IC | HX8273 |
Operating Temperature | -20~70C |
Storage Temperature | -30~80C |
Touch screen | Can custom resistive and capacitive touch screen |
Application | E-Bike,Medical, hand-held device, industrial, EV-chargers |
