0.96 inch 80*160 bay type resolution LCD display

Item0.96 inch 4 Line SPI Interface TFT LCD display
Model No.PV096004D0115D
Resolution80*160
Outline Dimension (mm)13.50*27.95*1.6
Active Area (mm)10.8 *21.696
Viewing AngleIPS
Brightness300nits
Interface4 Line SPI Interface
Backlight/
Driving ICNV3022B
PIN No.15
Operating Temperature-20~70C
Storage Temperature-30~80C
Touch screenCan custom resistive and capacitive touch screen
ApplicationMedical, smart bracelet, Hand-held, industrial

For product pricing,customization,or other inquiries:

Share to:

  1. TFT lcd display
  2. Stable supply
  3. All/wide/full viewing angle
  4. 300nits brightness
  5. Can custom resistive touch and capacitive touch
