1.06 inch 90×160 resolution LCD display

Item 1.06 inch 96×160 resolution IPS LCD display
Model No. PV10600H0713A
Resolution 80*160
Outline Dimension (mm) 16.32*29.76*1.68
Active Area (mm) 13.82*23.04
Viewing Angle 12 O’clock
Brightness 300nits
Interface 4 line SPI
Backlight 1*1LED
Driving IC GC9107
PIN No. 13
Operating Temperature -20℃~70℃
Storage Temperature -30℃~80℃
Touch screen Can custom resistive and capacitive touch screen
Application Medical, hand-held device, industrial, smart watch

For product pricing,customization,or other inquiries:

INQUIRY

Share to:

  1. TFT LCD
  2. 96×160
  3. Stable supply
  4. TN viewing angle
  5. SPI interface
  6. 300nits brightness
  7. Can custom resistive touch and capacitive touch
  8. Medical, hand-held device, industrial, smart watch
