2.0 inch 240*320 Transreflective resolution TFT LCD display

Item2.0 inch 240*320 MCU Transreflective lcd display
Model No.PV02014R0330S
Resolution240*320/QVGA
Outline Dimension (mm)36.72*52.74*2.4
Active Area (mm)30.6*40.8
Viewing Angle8 O’clock
Brightness260nits
InterfaceMCU
Backlight1*3 LED
Driving ICST7789V2
PIN No.30
Operating Temperature-20~70C
Storage Temperature-30~80C
Touch screenCan custom resistive and capacitive touch screen
ApplicationMedical, hand-held device, industrial, smart watch, E-bike

For product pricing,customization,or other inquiries:

Share to:

  1. TFT LCD DISPLAY
  2. 240*320/QVGA
  3. Stable supply
  4. All/Full/Wide/IPS viewing angle
  5. MCU interface
  6. Can custom resistive touch and capacitive touch
  7. Medical, hand-held device, industrial, smart watch, E-bike
