Kingtech PV05708D0140J-CT is a 5.7 inch 720*1440 dots TFT LCD module

Item 5.7inch 720*1440 LCD Gorilla capacitive touch display
Model No. PV05704Y0430E
Resolution 720*1440
Outline Dimension (mm) 73.23*145.99*2.93
Active Area (mm) 64.8*129.60
Viewing Angle All
Brightness 500nits
Interface MIPI 4 lane
Backlight 7*2LED
Driving IC JD9365D
Pin No. 30
Operating Temperature -10~60C
Storage Temperature -20~70C
Touch screen Capacitive touch optional
Application Industrial, Medical, Smart Home, Home appliance, Meter, outdoor

For product pricing,customization,or other inquiries:

Share to:

  1. 5.7 inch 720*1440 LCD with capacitive touch
  2. Full/Wide/All viewing angle
  3. High brightness/Sunlight readable/Outdoor
  4. Support MIPI interface.
  5. Can custom capacitive touch

5.7 inch 720*1440 dots TFT LCD module

5.7 inch 720*1440 dots TFT LCD module
